1260SH Ceramic Fiber Blanket

1430 SHZ Ceramic Fiber Blanket

Size of CCEWOOL ceramic fiber board

Thickness

Density(kg/m3)

Length

Width

Thickness

Density(kg/m3)

Length

Width

mm

64

96

128

160

mm

inch

64

96

128

160

inch

'

6

-

○

21840

610

0.24''

-

○

13

-

○

√

○

14640

0.5''

-

○

√

○

576.4''

24''

19

-

√

○

9760

0.74''

-

√

○

384.3''

25

○

√

7320

1''

○

√

288''

38

○

√

4880

1.5''

○

√

4880''

50

○

√

-

3660

2''

○

√

-

3660''

Excellent chemical stability;

Excellent thermal stability;

Excellent tensile strength;

Low thermal conductivity;

Low heat capacity;

Excellent insulation properties;

Good sound insulation.

Back lining material;

Furnace masonry expansion joints, door, roof heat insulation seal;

High temperature pipe insulation material;

Module / folded module processing material;

Fireproof coating.

If you want to Inquire this product, electronic catalogs, samples, fill in the following information.

*Name

*Country

Job title

*E-mail

*Tel

Phone Number

*Company

Company Web

Skype

Viber

Address

Inquiry




	Purer raw material, using pure alumina power as raw material with fewer impurities. Thus, PUREWOOL ceramic fiber blanket’s shot content is only 10%, which is 3% lower than others.

The first factory which adopts inside needles flower craft. Tensile strength reaches 0.055MPa, which is 20% to 30% higher than others. CCEWOOL ceramic fiber blanket’s service life is 3 years, which is 20% longer than others.

The color is whiter due to the less shot content.

Manufactured as per ISO9000 standard; weigh before packing to guarantee the actual weight of each roll is no less than theoretical weight.

Able to manufacture ceramic fiber blanket’s width varies from 50mm to 1220mm, thickness varies from 6 to 60mm.

?
Download Technical data sheet	Download MSDS	Download CE	Download TUV

CCEWOOL PUREWOOL series ceramic fiber blanket
Classification Temperature		1260 PST (2300℉)	1430 PHZ (2600℉)
Operation Temp(℃)		1100	1350
Density (kg/m3)		96/128/ 160
Permanent Change on Heating (%), EN1094-1
After 24 hours @950℃		-	-
@1000℃		1.5	-
@1100℃		2	-
@1200℃		2.7	1
@1300℃		5.5	2
@1400℃			3
Tensile Strength(Kg/m3), EN1094-1 KPa
Density 96kg/m3		60	60
128kg/m3		85	85
160kg/m3		120	120
Heat Conductive Co-efficient W/(m·k)(128kg/m3)
Temperature	@200℃	0.07	0.06
	@400℃	0.12	0.1
	@600℃	0.2	0.15
	@800℃	0.3	0.2
	@1000℃	0.35	0.3
Chemical Composition of ceramic blanket (%)
Al2O3		45-46	35-38
Al2O3+SiO2		≥99	-
ZrO2		-	15-17
Al2O3+SiO2+ZrO2		-	≥99
Fe2O3		≤0.15	≤0.2
Na2O+K2O		≤0.2	≤0.2
CaO+MgO		≤0.1	≤0.1

Size of CCEWOOL ceramic fiber board

Thickness

Density(kg/m3)

Length

Width

Thickness

Density(kg/m3)

Length

Width

mm

64

96

128

160

mm

inch

64

96

128

160

inch

'

6

-

○

21840

610

0.24''

-

○

13

-

○

√

○

14640

0.5''

-

○

√

○

576.4''

24''

19

-

√

○

9760

0.74''

-

√

○

384.3''

25

○

√

7320

1''

○

√

288''

38

○

√

4880

1.5''

○

√

4880''

50

○

√

-

3660

2''

○

√

-

3660''

Note: (○) and 1220mm width can be customized according to customer (order amount should not be less than the minimum order quantity)

(√) for conventional products

(-) for the product specification that can not provide

The first agent of CCEWOOL

As the result of shared cognition of the importance of constant quality, we won the most famous refractory material manufacturer and supplier in Turkey as our agent. Now, our agent has dominated ceramic fiber market in Turkey and also has some influence in Middle East area for the past 5 years of being CCE WOOL agent.

Our Turkey agent is a famous family-run company, which was founded in 1978, producing mainly unshaped refractory material. Their main business includes various refractory materials retails and furnace construction. They used to order ceramic fiber materials from some other Chinese suppliers, but they were bothered by the un-prompt sales service, un-flexible lead-time and unstable quality etc. in the past cooperation.

On 2009 Ceramitec Munich fair, as the only ceramic fiber products manufacturer from china, Double Egret attracted extensive attention, our Turkey agent also noticed us on this fair. After some brief communication, they were attracted by our green package, superior quality and fast lead-time and placed order to us on the spot.

After establishing business relationship, our agent was touched by our devotion to this job. Even though there is a 7 hours time gap between China and Turkey, we always managed to answer their question and provide effective solution before they went off work. Even through, Double Egret and we have 7 hours time gap, their responses are faster than our local suppliers thats what they commented on us in the email. Now, the Turkish agent has become one of our earliest and most loyal customers, because they think we are quick and flexible in lead time, easy to work with in cooperation. Besides, we can also provide both competitive price and most important some referential advice for their furnace construction.

In 2011, ceramic fiber market in Turkey went into a mess of unfair competition, our Turkey agents sales were heavily affected. Despite of the bad ceramic fiber market situation and reduction of sales, our Turkish agent and we insisted on guaranteed quality and rejected to do as others do. All our insistence on principal was paid back next year. After the recovery of Turkish market, for its being honest in the depression, CCE WOOL ceramic fiber became more popular in Turkey, won some new customers and got favorable comments in this industry. When Rosen Peng met with the manager of our agent in Turkey in METE Dusseldorf in 2011, they had some in-depth communication and reached a consensus that they and Double Egret had the same principal in running a company, So they proposed a more comprehensive cooperation in the future, they asked us to be our CCE WOOL ceramic fiber brand agent, and faced the future challenge together.

In 2012, we came to attend the Ankiros in Turkey with our CCE WOOL ceramic fiber products including ceramic fiber blanket, ceramic fiber board, ceramic fiber module, ceramic fiber paper, ceramic fiber rope, ceramic fiber cloth etc. The high-quality goods and good service we displayed on the international fair did great help for our agent to exploit Turkey market. Also, through some comparison at the fair, our Turkey customer had more confidence in us and became our CCE WOOL brands first agent in Istanbul.

In 2013, we made a mistake and shipped ceramic fiber boards of wrong density. But when we realized this mistake, we tried our best to reduce our customer's loss, we told the customer this problem on the spot and then we began to make some negotiations. During the negotiation, our Turkey agent was willing to communicate with their end users and find out a reasonable solution. Finally, we agreed on a mutually satisfying compensation plan. This incident also enhanced the trust between us.

In 2014, on MCE in Italy, we had an in-depth communication on how to protect their local customer source. They showed great satisfaction on our newly launched Customer Relationship Management System which could thoroughly protect the customer resource in Turkey and guarantee his benefit. We looked back on the past and looked forward to the future and agreed to extend our cooperation. Besides that, they exchange their opinion on ceramic fiber market and Chinese supplier. They finally came to a consensus that the only way to protect your market was to treat quality as the highest priority of a brand. At the same time, they showed their appreciation on the constant quality of our CCE WOOL brand through all these years of cooperation and they said that they would display all our ceramic fiber products on the Turkey fair this year. This in-depth communication strengthened our relationship.

There are 23 production lines for ceramic fiber blanket to guarantee the prompt delivery.

The needling panel which is used in needling links is changed every day to ensure an even distribution of the needling patterns.

Inspection: Supply Lab report for each shipment.

All of our products are certified by the following certificate,CE, TUV, BV and SGS.

Packing: Carton box or woven bags.

The outer packing of our carton box is made of five layers of kraft paper; the inner packing is plastic bags, which are suited for long distance shipments. The green package design shows the environmental protection idea and that are enjoying great popularity among the customer.

Supervision is requested for all the goods; and we also provide loading report and concerning pictures.

Why choose us

Why is CCEWOOL the top ceramic fiber export brand in China?

1

It is the second largest ceramic fiber manufacturer in Asia.

As the second largest ceramic fiber manufacturing base in Asia, CCEWOOL has its own ceramic fiber raw material production base. It is the earliest ceramic fiber manufacturer in China which is equipped with 23 ceramic fiber blanket production lines, 4 automatic ceramic fiber felt and board production lines, 2 ceramic fiber paper production lines and 2 ceramic fiber textile production lines, covering a factory area of 80,000 square meters and reaching annual output of more than 60,000 tons.

2

Having exported to more than 30 countries, CCEWOOL has earned a world-renowned reputation.

So far, we already have 10 years export experience and have exported to more than 30 countries and regions worldwide, including Germany, France, Italy, Japan, North America and some African countries.

3

Quality is guaranteed since we are the only enterprise who can provide CE certificate of ceramic fiber in China.

We strictly implements ISO9001 quality control system in production and all products have met CE certificate standards (EC.1282.0P140416.ZFRQX35). CCEWOOL is the only ceramic fiber manufacturing brand that has passed certificates of BV and TUV factory inspection at the same time in China.

Why does CCEWOOL have its agents make more profits?

1

Double Egret provides professional CRM system to every agent to realize systematic management and protect agents customer resources. Agents can get rid of any concern by our regional agent protection and guarantee of customers profit.

2

From 2009 to 2015, Double Egret has continuously attended METEC in Dusseldorf Germany, CERAMITEC in Munich Germany, ANKIROS in Istanbul Turkey, METAL EXPO in Russia, AISTECH in America, INDO METAL in Indonesia, TECNARGILLA in Italy, METAL in Poland. All the attendance has not only improved CCEWOOL brand reputation but also has witnessed customers approval and recognition of CCEWOOL quality. By virtue of brand strength and product quality, CCEWOOL obtains high attention and acceptance from visitors and exhibiting companies.

3

More than 10 years export experience and professional document-operation team enable us to be familiar with many countries import-export policies and regulations, such as policies in some European and American countries as well as Soncapc in Nigeria. We will provide reasonable solutions to all problems concerning the products within 24 hours after customers pick up the goods.

For 10 years, who are using CCEWOOL?

10 years hard work has enhanced CCEWOOL brand popularity and reputation at the international ceramic fiber market. And we are keeping good cooperation relationships with many multinational corporations, such as Rath, Vesuvius, Calderys and Mobil etc.
