Temperature Grade 1600℃（2912℉）

CCEWOOL Polycrystalline Wool Fiber Paper is designed for high temperature applications up to 1600°C. Manufactured from high purity Alumina fibres, using advanced production techniques to ensure uniform fibre distribution and close control of thickness and density.

CCEWOOL Polycrystalline Wool Fiber Paper is produced using Alumina fibres with the minimum addition of carefully selected bonds, which burn out in service. The ultra-clean 'shot' free properties of the product promote excellent handling and strength characteristics. CCEWOOL Polycrystalline Wool Fiber Paper has significant benefits as a separating and parting media for vacuum brazing applications and heat treatment. Other applications include gaskets and seals in furnaces with reducing atmospheres and hot isostatic pressing.

Almost no shot, white color, and high purity of raw materials

Good high temperature resistance and good high-temperature stability

Extremely low thermal conductivity, low linear shrinkage after heating

Stable chemical properties and strong corrosion resistance

Uniform fiber diameter and high tensile strength

Excellent thermal stability and thermal shock resistance

Excellent chemical stability

Expansion joints in industrial furnace linings

Strips in new fiber module lining overcome shrinkage

Gap filling for lining maintenance/repair

High Temperature Gaskets and Seals

If you want to Inquire this product, electronic catalogs, samples, fill in the following information.

*Name

*Country

Job title

*E-mail

*Tel

Phone Number

*Company

Company Web

Skype

Viber

Address

Inquiry




	High temperature resistance: Ceramic fiber paper can withstand extremely high temperatures, typically up to 1600°C (2912°F). This makes it an excellent choice for applications that require insulation in high-temperature environments, such as furnaces and kilns.

Low thermal: Ceramic fiber paper has low thermal conductivity, which means it is a good insulator and can effectively reduce heat transfer. This property helps to conserve energy and maintain optimal temperature levels in industrial and applications.

Excellent chemical resistance: Ceramic fiber paper has excellent resistance most acids, alkalis, and chemicals. It is non-corrosive and does not react most substances, making it a suitable choice for applications that involve exposure to aggressive chemicals.

Excellent dielectric strength: Ceramic fiber paper has excellentlectric strength, which makes it an ideal material for electrical insulation applications. It can effectively insulate and protect electrical components from high temperatures and electrical arcing.


Download Technical Data Sheet	Download MSDS	Download CE	Download TUV

CCEWOOL PCW Fiber Paper
Typical Chemical Analysis (fibre wt. %)
AI2O3	71-73
SiO2	27-29
Trace	<0.5
Physical Properties
Colour	White
Classification Temperature (°C)*	1600(2912℉)
Product Density (kg/m3)	160
Product Thickness (mm)+	8
Loss on Ignition (wt. %)
from Fibre	0
from Felt	<12

V company is a large scale international company in Malaysia. We had had a pleasant communication with them at the Munich exhibition in 2009. At that time, they were impressed by our spiritual outlook and professional attitude and decided to cooperate with us on the spot. As we all know, it usually requests all units to cooperate in operation in large corporation, even for a relative small order. Fortunately, based on my years’ experience working in international department of a listed company, I am very familiar with their operating process, so I tried my best to express a case concisely to save their time and promote the communicating efficiency between us.

CCEWOOL

Actually, we came across some difficulties during the cooperation with them, for example, it might be slow for them to confirm a thing for the complex division in Group Corporation, while they were urgent in the delivery of the goods. This led to some difficulties in our processing, however with my previous experience; I handled each process flexibly and got rid of the trouble of communication which might be existed in some small companies with no experience of working with large corporations. In addition, considering their requirements on delivery speed, we adjusted our order processing; deliver the goods before receiving the money. All our efforts above finally managed to guarantee our smooth cooperation.

We have special inspector to inspect each shipment of cargo. And a test report is provided before the product leaves the factory to ensure the quality of each shipment of CCEWOOL products.

Accept third party inspection (Like SGS, BV, etc.)

Production in strict accordance with ISO9001 quality control system.

Weigh before packing to ensure product’s actual weight is higher than theoretical weight.

Packing cartons are made of 5 layers of kraft paper. Inside carton is plastic film to prevent moisture. Suitable for long distance transportation.
