Ceramic fiber back-lining board|ceramic insulation board

1050 standard Ceramic Fiber back-lining Board

1260 standard Ceramic Fiber back-lining Board

Size of CCEWOOL ceramic fiber board

Categories		Typical Size Ceramic Fiber back-lining Board.
（kg/m3）Density		220kg/m3 to 260kg/m3
Common Size（mm）	L x W	1200x1000;1200x600;1000X1000;1000X600; 900x600; 600x300
	Thickness	10-80mm
Packing		Inner Plastic Bag + Outer pallet or Carton

Low heat capacity, low thermal conductivity;

High compressive strength;

Non-brittle material, good elasticity;

Accurate sizes and good flatness

Easily molded or cut, easy to install

Continuous production, even fiber distribution and stable performance;

Excellent thermal stability and thermal shock resistance;

Cement and construction materials: furnace back thermal insulation lining.

Ceramics industry: lightweight kiln car structure and the furnace hot face lining, separation and fire position for all kiln temperature zones;

Petrochemical industry: as high-temperature furnace hot surface lining material;

Glass industry: As furnace hearth back insulation lining, burner blocks;

Hot surface refractories, heavy refractory back linings, expansion joints.

Firebrick back lining for tundish, slot cover and aluminum plant electrolytic reduction cell;

All heat treatment furnace lining, expansion joints, backing insulation, thermal insulation and mold insulation, steel mill ladle, tundish, ladle and refined ladle back linings.

If you want to Inquire this product, electronic catalogs, samples, fill in the following information.

*Name

*Country

Job title

*E-mail

*Tel

Phone Number

*Company

Company Web

Skype

Viber

Address

Inquiry


The raw material for CCEWOOL ceramic fiber board is strictly selected from self-owned ceramic board raw material base. It is calcined in specialized rotating kiln, so the ceramic fiber bulk for ceramic fiber board is 5% lower in slag content than similar refractory fiber on the market.

	Double Egret is equipped with the only full automatic ceramic fiber board production line in China which has better stability than traditional vacuum forming ceramic board production line.

Compared with the refractory fiber board which is dried by traditional drying methods, our ceramic board have 5% better compressive and rupture strength than products of the same density.

Compared with vacuum forming ceramic fiber board, CCEWOOL ceramic fiber board has better flatness. The specification tolerance is +/-1mm.


Download Technical Data Sheet	Download MSDS	Download CE	Download TUV

Types (℃)		1050	1260
Permanent Change on Heating		950℃x24h≤-2.5	1050℃x24h≤-2
Theoretic Heat Conductive Co-efficient W/(m·k)(128kg/m3)	heat transfer 800℃	≤0.116	----
	heat transfer 1000℃	----	≤0.135
Compression Strength (MPa)		≥0.1	≥0.25
Theoretical density (kg/m3)		220	260
Water content %		≤1
Organic content %		≤8
Typical size		1200x600x25mm; 1200x600x50mm
Package		Cartons or pallets

Size of CCEWOOL ceramic fiber board

Categories		Typical Size Ceramic Fiber back-lining Board.
Density(kg/m3)		220kg/m3 to 260kg/m3
Common Size(mm)	L x W	1200x1000;1200x600;1000X1000;1000X600;900x600; 600x300
Thickness		10-80mm
Packing		Inner Plastic Bag + Outer pallet or Carton

The agent of CCEWOOL

[Preface]He is an oversea Chinese and has lived in Indonesia for years. He is very familiar with chinese market and Chinese culture. After years of hard work, he has become a famous enterpriser in Indonesia. When he came to visit our company, we give him a warm welcome, our manager - Mr. Rosen drove 5 hours to meet him at the airport. During the factory visit, he was really surprised at our 60000 square meters’ factory, 23 ceramic fiber production lines and automatic loading system. After years of cooperation, we build a brother relationship.

In 2010, with the development of CCE WOOL ceramic fiber’s reputation in the international market and the increasement of our former customers’ recommendation, a famous Indonesia factory came to us for cooperation. He is an oversea Chinese who lived in Indonesia for years. He has his own local house and also a branch in China. After knowing he was an oversea Chinese, Rosen peng drove 5 hours to meet him at the airport and escorted them to the factory to show our respect. This customer had been in refractory industry for a very long time and had seen numerous ceramic fiber factories, but when he saw our factories, he was also surprised by the modernization of the factory. We have 60000 square meter’s factory, 23 ceramic fiber production lines. This pleasant visit began our cooperation smoothly; from then on this Indonesia customer had frequent and stable orders from 2008 to 2013.

We also introduced some of our customers who ordered small amount to them. Now they have developed into our largest agent in Indonesia. The products they ordered increased from ceramic fiber blanket only into the whole ceramic fiber products including ceramic fiber blanket, ceramic fiber board, ceramic fiber paper, ceramic fiber module, ceramic fiber cloth etc. In 2013, they invited Rosen peng and his wife Amanda meng to attend the INDOMETAL Jakarta Indonesia. During the fair, we received very warm welcome, they arranged someone to show us around Indonesia and explain the local culture and history to us. Through this customer we feel more deeply the importance of good quality.

The length of full automatic production line is 150m, daily output is 20tons.

The automatic production lines are equipped with automatic drying system which can guarantee a thorough drying in 2 hours and better drying results.

Compared with the ceramic fiber board which is dried by traditional drying methods, our products have 5% better compressive and rupture strength than products of the same density.

Double Egret is equipped with the only full automatic ceramic fiber board production line which has better stability than traditional vacuum forming production line. Compared with vacuum forming ceramic fiber board, CCEWOOL ceramic fiber board has better flatness. The specification tolerance is around 1mm.

Inspection: Supply Lab report for each shipment.

Carton which is made of five layer of kraft paper and suitable for long distance shipment and exporting shows the environmental protection idea and enjoys great popularity among the customers.

Three packing methods: packed with carton box; packed with wooden pallet

Our warehouse:The daily output is 8 tons due to the large capacity of full automatic ceramic fiber board production line, which could ensure the timely delivery.

Loading supervision is requested for all the goods, we provide loading report and concerning pictures

WHY CHOOSE US

◆

CCEWOOL

Why is CCEWOOL the top ceramic fiber export brand in China?

1

It is the second largest ceramic fiber manufacturer in Asia.

As the second largest ceramic fiber manufacturing base in Asia, CCEWOOL has its own ceramic fiber raw material production base. It is the earliest ceramic fiber manufacturer in China which is equipped with 23 ceramic fiber blanket production lines, 4 automatic ceramic fiber felt and board production lines, 2 ceramic fiber paper production lines and 2 ceramic fiber textile production lines, covering a factory area of 80,000 square meters and reaching annual output of more than 60,000 tons.

2

Having exported to more than 30 countries, CCEWOOL has earned a world-renowned reputation.

So far, we already have 10 years’ export experience and have exported to more than 30 countries and regions worldwide, including Germany, France, Italy, Japan, North America and some African countries.

3

Quality is guaranteed since we are the only enterprise who can provide CE certificate of ceramic fiber in China.

We strictly implements ISO9001 quality control system in production and all products have met CE certificate standards (EC.1282.0P140416.ZFRQX35). CCEWOOL is the only ceramic fiber manufacturing brand that has passed certificates of BV and TUV factory inspection at the same time in China.

Why does CCEWOOL have its agents make more profits?

1

Double Egret provides professional CRM system to every agent to realize systematic management and protect agents’ customer resources. Agents can get rid of any concern by our regional agent protection and guarantee of customers’ profit.

2

From 2009 to 2015, Double Egret has continuously attended METEC in Dusseldorf Germany, CERAMITEC in Munich Germany, ANKIROS in Istanbul Turkey, METAL EXPO in Russia, AISTECH in America, INDO METAL in Indonesia, TECNARGILLA in Italy, METAL in Poland. All the attendance has not only improved CCEWOOL brand reputation but also has witnessed customers’ approval and recognition of CCEWOOL quality. By virtue of brand strength and product quality, CCEWOOL obtains high attention and acceptance from visitors and exhibiting companies.

3

More than 10 years’ export experience and professional document-operation team enable us to be familiar with many countries’ import-export policies and regulations, such as policies in some European and American countries as well as Soncapc in Nigeria. We will provide reasonable solutions to all problems concerning the products within 24 hours after customers pick up the goods.

For 10 years, who are using CCEWOOL?

10 years’ hard work has enhanced CCEWOOL brand popularity and reputation at the international ceramic fiber market. And we are keeping good cooperation relationships with many multinational corporations, such as Rath, Vesuvius, Calderys and Mobil etc.
